Separator ME

Vibrowest Separator ME Image

Overview

MR circular screen separator segregates solids from liquids or dry material into
various particle sizes ranging from 51 mm to 0,033 mm  (400 mesh).

Easy to install, can be equipped to separate up to 5 sizes with up to 4 screen decks incorporated
in one Vibrowest separator.

Standard models range in size from 440 mm to 1800 mm

Screens are easy and fast to change and can be equipped with various cleaning system as: balls,
kleeners, starbrush, CIP and the innovative ultrasonic cleaning system

The separator is avaiable constructed of carbon steel, stainless steel AISI 304
or stainless steel AISI 316.

On request: ATEX certification, FDA IQ-OQ procedure, GMP avaialable.

All product contact areas can be polished to be in accordance with Sanitary Standards.

Operation

The vibration is develop in both the horizontal and in the vertical plane and can be adjusted in both directions

Vibration is accomplished by eccentric weights positioned on fly wheels on the upper and lower ends of the motion generator shaft.

The upper fly wheel creates vibration in the horizontal plane, which moves the material from the center to the outer perimeter of the
screen. The lower fly wheel creates vibration in the vertical as well as tangential plane producing a highly efficient sieving action.

Adjusting the counterweights on the fly wheel is rapid and tool free. This adjustment allows modifing the vibration pattern to find
the best sieving action for a particular product.

The ability to adjust the vibration pattern results in the high screening efficiency both with liquid and solid products.

Vibrowest Separator ME Image
Vibrowest Separator ME Image

Advantage

Vibrowests 45 years of experience in sieving technology, innovative and efficient design has brought
Vibrowest Sieves to the highest levels of efficiency and reliability.

The MR sieves can be modified and adapted to suit a wide variety of customer requirements.
